Designed for the future
Win with VRV 5 S-series
In addition to all the unique new features of the VRV 5 S-series, there’s now even more to be won. Between 1st June and 29th October 2021 inclusive, for all invoiced orders of VRV 5 outdoor units you’ll be in with a chance of winning one of five prizes, including a brand new VanMoof Electric Bike.
TOP PRIZE is a VAN MOOF S3 electric bike. For the 2nd prize winner, we have an iPad Air 256GB. In 3rd place, we have a DJI Mavic Mini 2 Drone. 4th prize is a pair of Sony WH 1000XM4 wireless head phones. And the fifth and final prize is a Sonus Roam Smart Speaker.
Contact your sales engineer to place an order today.
It’s as simple as VRV 5!
Industry-leading serviceability and handling
- Low-height single fan range
- Easy to transport thanks to compact design
- Wide access area to easily reach all key components
- No leak check requirement for majority of installations
Best-in-class design versatility
- Shîrudo technology allows flexible indoor unit installation in rooms with a minimum surface down to 10m²
- Sound pressure down to 39 dB(A) thanks to 5 low sound steps to suit the application
- Automatic ESP setting up to 45 Pa to allow ducting
Geared for comfort
- Intuitive online and voice control
- Variable Refrigerant Temperature for optimal comfort
- Specially designed new 10 class indoor unit for small, well-insulated rooms
1. Unique 3-row heat exchanger
✓Contributes to top seasonal efficiency
2. Specially designed grille
✓ Low pressure drop
✓ No risk for accidental reach of the fan
3. New casing design with four handles for easy carrying
4. New asymmetric fan design
✓ Two high ESP settings
✓ Low sound levels
5. Compact dimensions
✓ Easy to transport and hide thanks to compact size and single-fan design
✓ Less use of natural resources to produce
6. Refrigerant cooled PCB
✓ cool/heat selector input
✓ 7-segment display for quicker and more precise error and setting reading
7. New stop valves
✓ Repositioned to allow front or side connection
✓ Brazed for increased reliability
8. Unique Daikin swing compressor
✓ No abrasion possible
✓ No refrigerant leak possible
✓ High seasonal efficiencies
Connectable indoor units
|Round flow cassette||360° air discharge for optimum efficiency and comfort||FXFA-A|
|Fully flat cassette||Unique design that integrates fully flat into the ceiling||FXZA-A|
|Slim concealed ceiling unit||Slim design for flexible installation||FXDA-A|
|Concealed ceiling unit with medium ESP||Slimmest yet most powerfull medium static pressure unit on the market!||FXSA-A|
|Wall mounted unit||For rooms with no false ceilings nor free floor space||FXAA-A|
Advantages of R-32
› Lower Global Warming Potential (GWP): only 1/3rd of R-410A
› Lower refrigerant charge: 15% less compared to R-410A
› Higher energy efficiency
› Single component refrigerant, easy to handle and recycle
Maximum flexibility out of the box.
With Shîrudo technology your VRV 5 system takes care of small room applications in your building, without the need for any additional considerations and equipment in the field.
Thanks to the factory-integrated measures, VRV 5 is the most flexible and quick to design, fully compliant to the latest product standards.
